Pipe Rolling Machine VCW/HD 50
The VCW/HD 50 is a heavy-duty Pipe Rolling Machine designed for demanding industrial applications. It is powered by a 3 HP, 1440 RPM motor integrated with an inline helical gearbox, delivering smooth operation at 7 RPM. The hydraulic system includes a 2 HP, 1440 RPM motor with a 30-litre oil tank, driving two powerful 10-ton cylinders for high-pressure, consistent bending. Capable of handling pipes up to 50 mm in diameter and 4 mm in thickness, the VCW/HD 50 ensures precise bending results for thicker and tougher materials. Its solid build, weighing 950 kg, and spacious footprint of 940 mm × 1260 mm × 1390 mm offer enhanced stability and strength during operation. This machine is a reliable solution for high-capacity production environments, combining power, efficiency, and durability to meet the needs of fabrication workshops and industrial bending tasks.
| VCW/HD 50 | |
|---|---|
| SPECIFICATION | REMARKS |
| Motor | 3 HP, 1440 RPM/Inline Helical Gear Box |
| RPM | 7 RPM |
| Power Pack | 2 HP, 1440 Motor, 30 Litres Oil Tank |
| Cylinder Capacity | 10 Ton, 2 Cylinders |
| Size | 940mm X 1260mm X 1390mm |
| Weight | 950 Kg |
| Capacity | 50 dia X 4mm Thick (Max) |
